ER:ONE - Aero/Racing

The ER:ONE road frame represents a step forward in structural engineering. To achieve the combined goals of low weight, high stiffness, and reduced aerodynamic drag, every stage of development demanded precision. Each carbon ply is strategically oriented, resin ratios are optimized for strength-to-weight efficiency, and tube profiles are refined through repeated simulation and testing. From layup design to functional stress analysis, every parameter is verified and re-evaluated, ensuring a frame that balances efficiency, durability, and speed under real-world racing conditions.

Key Features

Aerodynamic Design
Aerodynamic Design
The fork features a more aerodynamic design, boosting overall performance and efficiency.
Advanced Materials
Advanced Materials
Built with premium Toray T1100 and M56 high-grade carbon fibers, the frame has exceptional stiffness and responsiveness.
Ultra-Light Integrated Handlebar
Ultra-Light Integrated Handlebar
Engineered for exceptional stiffness and precision handling — giving you total control in every corner.

Key Specifications

Model

  • ER:ONE

Material

  • T1100 & M65

HT

  • 52x52mm

BB

  • T47-68mm Threaded

Thru-axle

  • F/100×12mm R/142×12mm

Tire (Max.)

  • 700×32c

Brakes

  • Flat Mount Disc Brake

Weight

  • Frame:840g(±5%) Fork:445g(±5%) Seatpost:139g(±5%)

Wheels

  • RORE Steel Spoke, Aero 50, Aero 60, Lighter 50 or Lighter 60

Inner Tube
  • 700x28c
Saddle
  • SAMASSI 3D Print Saddle
Handlebar
  • CANWIN ZEPHYR SSL

Key Specifications

FRAME
Size Options
XS/430, SM/460, MD/490, LG/520, XL/550, XXL/584
Frameset
T1100 & M65 Modulus Carbon, Monolith One Piece Construction (840g)
Fork
NARROW option for lighter weight & improved handling (-25g) or WIDE option fork for optimized aerodynamics
BRAKES
Front Brake
Shimano BR-R8170
Rear Brake
Shimano BR-R8170
Brake Rotors
RT-CL800 (160mm Front/140mm Rear)
DRIVETRAIN
Shift Levers
Shimano ST-R8170
Front Derailleur
Shimano FD-R8150
Shimano 105 Di2: Shimano BR-R7170
Shimano Ultegra Di2: Shimano BR-R8170
Rear Derailleur
Shimano RD-R8150
Cassette
Shimano CS-R8101-12 (11/34T)
Chain
Shimano CN-M8100
Crankset/Chainrings
Shimano FC-R8100 165/170mm length options & 50/34 or 52/36 chainrings
Bottom Bracket
QuickPro/SSpade Stainless Steel T47/68mm

Size & Fit

Ref Specification XS / 430 S / 460 M / 490 L / 520 XL / 550 XXL / 584
A Frame Size / Seat Tube Length (mm) 430 460 490 520 550 584
B Effective Top Tube Length (mm) 515 525 540 558 575 596
C Seat Tube Angle (°) 75.0 74.5 74.0 73.5 73.5 73.0
D Head Tube Angle (°) 70.0 71.0 72.0 73.0 73.0 73.5
E Head Tube Length (mm) 105 118 132 148 165 185
F Chainstay Length (mm) 408 408 408 408 408 408
G Wheelbase (mm) 985 985 987 991 1008 1019
H Fork Offset / Rake (mm) 45 45 45 45 45 45
I Bottom Bracket Drop (mm) 70 70 70 70 70 70
J Fork Length (mm) 373 373 373 373 373 373
K Standover Height (mm) 746 762 779 797 813 846
Stack-to-Reach Ratio (STR) 1.32 1.36 1.39 1.40 1.40 1.42
Reach (mm) 380 381 386 393 406 415
Stack (mm) 505 521 538 556 572 593



  • 5 stars: 20 (80%)
  • 4 stars: 4 (16%)
  • 3 stars: 1 (4%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
M
Mattia Cighetti

Bici Top, personalizzazione Top, reattiva veloce. SIGARI!!!

M
Mattia Cighetti

Bici spettacolare

A
Aaron Choo

Firstly the bike felt very responsive and stiff. On top of the bike, the main thing i want to comment here is actually the support customer service especially Emily and Fei. They have been veryvattentive towars my issues raised from logistic to refund due to wrong sizing delivered. It was a smooth and hassle free support from them and QP.

R
Rs

Best from both world, cheaper and almost same preformance as dura ace

L
Lucas Maurer

Great bike! Met almost all expectations. Top quality to the last screw! But the customer service has mentioned that bike is ready to ride. This is not so. You have to be technically very ready to make the Vike roadworthy (assemble).

A
Anonymous

Quite happy with the Quickpro Er:one shipped quickly received well packed and very impressed with overall quality and feel of the bike.

C
Chris

I love this bike! It is an absolute blast to ride. I replaced my Canyon Aeroad CFR with the ER One and it is an all around better bike. It’s more nimble and accelerates much better off the line and does not feel as sluggish as the Canyon. It’s huge bang for buck and an incredible value. Customer service was great so no complaints there. Would definitely buy from Quick Pro again.

R
Robert Walker

Awesome bike! I know everyone is hesitant to buy a Chinese bike, but China has come a long way in the technology race, it is no longer "cheap imitations". This bike is light, fast, and Aero, PLUS, you have a LOT of choice for a paint scheme, and let's face it, nobody wants to ride or own an ugly bike. I swear I gained about 2 mph(10%) over my 2016 bike for the same effort. My criticisms would be this. The bike arrives (almost ) fully disassembled. Only the hydraulic brake lines, shifters and handlebar tape are installed. Everything else needs to be assembled, like adding the rim strip to the wheels, etc. Directions are poor (only in Chinese)to say the least, and there are no pictures to help those that cannot read Chinese. The stem cannot be lowered more than 10mm without cutting the fork. Maybe this is standard with a carbon fork, I am not sure. The last "negative" item is that because the bike is so light, and has such thin walls, it has a tendency to magnify and echo any creaks or sounds, like the carbon spokes on the deep dish carbon wheels. Yeah, minor items to complain about, I know. As I said, overall I am VERY pleased with the bike, but I only have about 1500 miles on it so far.

E
Eric Hagstette

Fast. Smooth. Overall very happy. Wish it were a titch lighter.

a
andrea Beatrici

la bici è veramente bella ma soprattutto va molto veloce . Spettacolare alle alte velocità e molto reattiva anche in salita . Super consigliata per chi ama andare veloce in percorsi misti.

F
Facundo Nuñez

La bicicleta es increible, muy aerodinámica. Confortable, y además el manillar Canwin es un gran hallazgo porque es muy cómodo y resistente. Las ruedas con increíbles muy reactivas y muy cómodas!

C
Craig

This Bike far exceeds my expectations.
It is very neatly detailed. The Paint is flawless.
Assembly may be slightly challenging for some, especially since it lacks instructions. But, Quick Pro is new to the US market so I'm sure they are working on improving minor issues like this.

All of my rider friends are jealous of this bike and it's incredible value.

D
Douglas Chrystall

Really impressed with the QuickPro bike. It looks fantastic in person and rides even better than expected — very responsive, sharp handling, and feels quick as soon as you put the power down. The whole buying process was easy as well; the team were helpful, responsive, and straightforward to deal with. Great value for the spec and a bike I’m genuinely excited to ride. Highly recommended.

W
Werner Van Looy

The Quick-Pro ER ONE is a top bike, 1kg lighter than my Scott Foil. The geometry is perfect for me; with the wide fork, it steers a bit sluggishly at low speeds, but once up to speed, it is truly aero. Price-quality ratio is definitely worth it; a top bike for much less money than a major brand. Shimano Ultegra does what we expect of it. Wheels with upgraded carbon spokes (Carwin F50C) feel light, top-notch. I had ordered a narrow option fork, but upon arrival, I received a wide one. After contacting after-sales service, I got $100 back, which I could live with. The only downside is the assembly; they told me in an email that it was 80% assembled, only the wheels and the fork needed shortening, but this was not the case. Battery, derailleur, seatpost, saddle, brake discs, cassette, chain – all included separately, so that is the only downside I have to mention. I also had to go to the bike shop to get everything sorted out, which was an extra cost of €193. Keep this in mind if you order a complete bike. I think that's a bit of a shame.

N
Nicolas Blier

Incredible value and finishing. best bike I own.

H
Hassan Younes

I received the bike almost fully assembled, which made the setup very quick and easy.

In person, the bike looks even more beautiful than in the photos. The design and finish are really impressive, and the overall aesthetic exceeded my expectations.

The bike fully matches the specifications described on the website, and the build quality feels excellent. Everything looks well-made and carefully assembled.

I can't wait to take it out for a long ride and really test its performance on the road. So far, I am very satisfied with my purchase.

D
Denis Weidner

Excellent service with quick response! Beside the damaged brake, everything was fine with the delivery. The service member immediately helped me with getting money for a new disc brake and also helped me with some other questions. Bike quality is awesome

D
Derrick Yap

The bike is Fast!!! I love it!!!

R
Ramil

Not really good packaging! Theres some cratches all over, But bike looks great!

J
Jacob

Amazing bike

A
Anonymous

The bike is great. Relative easy for an amature to assemble, light,and solid.
The customer service leaves something to be desired. Not shipped from a US warehouse (I'm in Canada), and there was no tracking or updates for the three weeks it took for the bike to get into UPS' hands. Once UPS got it, things went smoothly.
