GRAVEL · RACE

GR:ONE FRAME

Name: GR:ONE FRAME
Brand: QUICK PRO US
SKU: GRONE-FRM-DIABLA
Price: 2099.0 USD
Availability: InStock

$2,099.00 USD

Color: Diamond Black

GR:ONE FRAME

GR:ONE - All Terrain Racing Gravel

Key Specifications

−

Model

GR:ONE Frame

Material

High-strength high-modulus carbon fiber

HT

52x52 mm

BB

T47-68mm Threaded

Thru-axle

F/100×12mm R/142×12mm

Tire (Max.)

700×45c

Weight

Frame:919g±(5%) Fork:459g(±5%) Seatpost:169(±5%)

Handlebar

CANWIN AELOUS (Outward Expansion)

Frame Specifications

−

FRAME

Size Options

XS/426, SM/456, MD/486, LG/516, XL/546

Frameset

High Modulus Carbon, Monolith One Piece Construction (919g Size M)

Fork

High Modulus Carbon, Tuned for Multi-Surface Riding (459g)

Size & Fit

−

Specification	XS/426	S/456	M/486	L/516	XL/546
Size / ST Length (mm)	426	456	486	516	546
Virtual TT (mm)	518	535	553	572	590
ST Angle (°)	74.2°	74°	73.6°	73.3°	73.8°
HT Angle (°)	70.5°	71°	71°	71°	71°
HT Length (mm)	95	113	132	152	172
RC Length (mm)	425	425	425	425	425
Wheel Base (mm)	1006	1016	1032	1048	1062
Fork Rake (mm)	55	55	55	55	55
BB Drop (mm)	75	75	75	75	75
Fork Length (mm)	400	400	400	400	400
Standover (mm)	723	742	760	779	798
Reach (mm)	370	379	388	398	405
Stack (mm)	524	543	561	580	599

5 stars: 9 (90%)
4 stars: 1 (10%)
3 stars: 0 (0%)
2 stars: 0 (0%)
1 star: 0 (0%)

I’m really impressed with this bike. The frame is extremely lightweight (size S is 735g), the fork is 488g, and the seatpost is 168g. After my first ride, the overall feeling is that the bike is very fast and responsive, yet comfortable as well. I don't think this will be the last bike I buy from Quick-Pro!

Super light, stiff and very fast🤌

Great bike! Build the frameset with my used parts from the previous bike. A bit watch out with the headset while assembling! Run the frame with 45mm tyres and 32mm inner width rims. The bike is just fast and is an absolutely cracker. Paintjob is really nice. I highly recommend the gravel bike for racing!

One of the best looking frames I've ever seen. The custom paint job is excellent, quality is on par with western brand and the weight is almost unbelievable for race gravel frame with 45mm tire clearance. Great.

Nice paintingJob, and the stiffnes is amazing.

Points positifs: cadre parfaitement peint, belles finitions, passage de câblerie complète, axes de roues, entretoises, diverses visseries… bref un cadre de qualité et complet.
Points à améliorer: délai de livraison 1 mois et 1 semaine (2-3 semaines annoncés…) et emballages à revoir, à l’arrivé du colis, on prend un coup de chaud à l’ouverture compte tenu du manque de protections.
Montage non effectué lors de la rédaction de ce message

Amazing paintjob on te frame, and in general a high quality of finish. Shipping was fast and customer service great .

Frame set including handelbar and seatpost is excellent quality and each detail is fantastic, construction look pretty accurate and well done. Otherwise they said they will send and extra gift of electric pump, some inner tubes plus wreck torx tool and I never recived it.

Absolutely beautiful paint job. Was easy to build even with fully internal routing. Handles amazing for both gravel and cyclocross.

Grat customer service. Received by GR one within 5 weeks!
