GRAVEL · ADVENTURE

XR:ONE RIVAL XPLR 1x13s

$4,999.00 USD

Color: Moss Green

Estimated Delivery:Aug 24 - Aug 28

XR:ONE RIVAL XPLR 1x13s

XR:ONE - Adventure Ready Gravel Frame with Integrated Tool Storage

Built for riders who want to go further, faster, and more prepared. Designed as a true adventure gravel platform, the XR:ONE blends modern gravel geometry with thoughtful integration for long distance exploration and bikepacking. At the core of the bike is a high performance monocoque carbon frame, engineered as a single continuous structure to deliver exceptional strength, efficiency, and refined ride feel across demanding terrain.

At the heart of the design is a integrated in-frame toolbox, allowing riders to store essential ride gear while maintaining a sleek, uninterrupted silhouette. XR:ONE turns every ride into a worry free adventure.

Key Features

−

Integrated Frame Storage

Built-in tool storage keeps your ride essentials secure, silent, and always within reach.

Adventure-Ready Mounting

Up to 26 mounting points across the frame and fork for bags, bottles, and full expedition setups.

50mm Tire Clearance

Run up to 50mm tires for maximum comfort, traction, and confidence on any terrain.

Key Specifications

−

Model

XR:ONE

Material

High-strength high-modulus carbon fiber

HT

52x52 mm

BB

T47-85.5mm Threaded

Thru-axle

F/100×12mm R/142×12mm

Tire (Max.)

700×50c

Brakes

Flat Mount Disc Brake

Weight

Frame:839g±(5%) Fork:449g(±5%)

Wheels

RORE Terra 32 Adventure Wheelset

Inner Tube

700x50c

Saddle

SAMASSI 3D Print Saddle

Handlebar

CANWIN AELOUS SSL

Frame Specifications

−

FRAME

Size Options

XS/475, SM/495, MD/515, LG/535, XL/555, XXL/585

Frameset

High Modulus Carbon, Monolith One Piece Construction (839g Size M)

Fork

High Modulus Carbon, Tuned for Multi-Surface Riding (449g)

Group Set Specifications

−

BRAKES

Front Brake

SRAM Rival AXS XPLR E1

Rear Brake

SRAM Rival AXS XPLR E1

Brake Rotors

SRAM Paceline A2 (160mm Front/160mm Rear)

DRIVETRAIN

Shift Levers

SRAM Rival AXS XPLR E1

Front Derailleur

N/A

Rear Derailleur

SRAM Rival AXS XPLR

Cassette

SRAM Rival CS-XG-1351-E1 (10/46T)

Chain

SRAM Rival AXS

Crankset

SRAM Rival XPLR 170mm length & 44T chainring

Size & Fit

−

Code	Measurement	XS (475)	S (495)	M (515)	L (535)	XL (555)	XXL (585)
A	Seat Tube Length (mm)	475	495	515	535	555	585
B	Top Tube Length (mm)	525.3	545.3	560	576.5	595.4	615
C	Seat Tube Angle (°)	74.5°	73.5°	73.5°	73.5°	73.5°	73.5°
D	Head Tube Angle (°)	70°	70.3°	70.5°	72°	72.5°	72.5°
E	Head Tube Length (mm)	120	135	150	170	190	210
F	Chainstay Length (mm)	435	435	435	435	435	435
G	Wheelbase (mm)	1029.5	1037	1051	1053	1067	1087
H	Fork Offset (mm)	50	50	50	50	50	50
I	Bottom Bracket Drop (mm)	70	70	70	70	70	70
J	Front Center (mm)	400	400	400	400	400	400
K	Standover Height (mm)	753	772	790	810	832	856
—	Stack-to-Reach Ratio (STR)	1.44	1.46	1.46	1.49	1.50	1.50
—	Reach (mm)	375	380	390	400	412	426
—	Stack (mm)	542	558	573	596	619	638
